Acoustic hood RF-26
• Durable, lightweight, chemical tesistant body
• Excellent low temperatures impact properties
• High performance polyurethane acoustic insulation liner, resistant to mildew and rot.
• Completely maintenance free and corrosion resistant, impervious to chemical attack
• Can be used both indoors, outdoors and offshore
• Easy Clean - Scratch Resistant
• Optional colors available upon request
• Special shape for higly noisy areas
• Designed for corrosive and saline atmosphere
• UV resistant and suitable for harsh environment
• Easy fixing system
• Suitable for heavy industrial telephones (up to 60 kg)
• Pass-trough hole on the shelf for cables inlet
• Fire Retardant
Introduction:
The acoustic hood is both suitable for commercial locations where appearances are important or industrial premises to brighten up the working environment. It is applied in offshore and onshore organic compound business, energy business, energy corporations then on. The acoustic hood has been designed to suit especially kinds of wall mounted phones.
Smaller wall mounted phones, or intercoms will be fastened into the 650mm high by420mm wide flat space within the back of the hood.
The thermo set composite moulding is factory-made victimization the most recent RTM Massachusetts Institute of Technology method, giving the RF-26 respectable strength and resistance to impact. it's appropriate for internal or external locations as well as use as a Marine phonephone Hood.
Recent re-styling has additionally enclosed moulded-in phone graphics to the edges and a distinct flat space to the front that permits the fixing of screen written graphics.
For external or internal use, the RF-26 is meant to realize a high level of noise reduction up to 23dB. Manufactured using general-purpose resin material Class 1 fire regulation,the RF-26 is extremely robust and weatherproof. Inside the hood's outer shell is a perforated polypropylene lining that houses 50mm non-hygroscopic acoustic insulation. Fitted to the inner back wall is a stainless steel apparatus plate or Cold rolled steel plate optional pls contact marketing stuff if you need this telephone plate.
The liner membrane provides excellent ambient noise rejection in the speech interference band between 400 Hz and 2400 Hz up to 23dBA. Corrosion proof construction and quality build ensure performance in applications including offshore installations, Refineries, Chemical plants and any industrial site where ambient noise inhibits efficient communications.
Telephone layout:
