Camera: Image Sensor:OV9712 Total Pixels: 720P(1280*720) 15fps
Min. Illumination:0.1lux Field of view:150° horizontal *Opposite 170°
Framerate:15fps, H.264 Lens size: 1/4 inch
VoIP SIP2.0 telephone DTMF dialing
MTBF:100000hours MTTR: 2 hours
Hotline call-- Browser configuration
Communication: Full duplex 2-way hands-free communication
Call Control Signaling: VOIP SIP Info(DTMF), RFC 2833(DTMF)
Local power, 12VDC,Idle 2W, Max 10W
Auxiliary Contacts:1 Aux Output, dry contact
Contact Ratings. Load: Resistive load
Rated load:0.3 A at 125 VAC; 1 A at 30 VDC
Rated carry current:1A
Max.switching voltage:125 VAC,60VDC
Max.switching current:1A
INSTALLATION
Audio Codes:G.711, G.722, G.729
Network:10/100 Base TX Ethernet, RJ45
connectors, Cat5e or better
IP Protocols: IPv4, UDP, DHCP, SIP
1 X LAN Protocols
1X WLAN(IEEE 802.3af), Network Access
Programming: Non-volatile flash memory
programming and configuration through Web GUI
Management and Operation:DHCP and static IP,
remote automatic software upgrade, centralized monitoring, status LED
Echo cancellation code:G.167/G.168
